Autoclave B Class

• Technical Datasheet Class B Autoclave

  Technical Parameters

• Sterilization level : European Class B standard - 23 Liters
• Sterilizing temperature: standard 134℃/121℃.( 136-138 ℃ adjustable))
• Special sterilization: Killing active HV,HBV,BSE and spore,
• Dry procedure: Strong vacuum drying ,the residual humidity<0.2%
• Display: Digital displaying various live data like temp, pressure and time.
• Test: Bowie & Dick Steam penetration test, vacuum test , Helix test
• Safety: Safety valve,
• Lock Security: Double door locking security, convenient and users friendly..
• Sterilizing record: Optional USB and printer.
• Water supply system: 3L distiller water tank,3L waste water tank
• Clean procedure: Automatic clean inside pipe and steam generator

• Instrument container : 5 levels with 3 mesh trays



Product Characters

1. Based on the new class B of international prEN13060, have 3 pulsating vacuum, Vacuum up to -0.9Bar (-0.09Mpa).Suitable to sterilizing wrap, unwrap, solid, porous, hollow device.
2. Use imported&advancedl6-bit microprocessor, easy to operate. Most suitable for the Dept of Stomatology , Ophthalmology, Surgery and Lab.
3. With B& D test and vacuum test procedures. To test the penetrability.
4. Chamber punched by Stainless Steel (#304, thickness: 2.5mm), together with The jet type of steam generator, selfcleaning ensure the efficient sterilizing.
5. With alarm system for waste water tank, avoid the waste water to enter into the sterilizing circulation, make the Sterilizing completely.
6. Precise LED digital display and advanced self-test system ensure you get the working data freely.
7. Double lock door system for safety during operating.
8. With built-in printer .USB optional. The disinfection process data and date automatically print.
