Description
XVbeam1000 (Handheld X-ray System)
Stable power allows for clear images
The voltage and current of 65Kv and 2.6mA generate more power to penetrate the teeth and obtain clear images. The focal spot size of 0.4mm significantly focuses more x-rays on the target teeth and produces a higher quality image on film or sensor.
Dual-protection design reduces user exposure to radiation
The safety of users is our priority. The XVbeam1000 features a dual-protection design
External Backscatter Shielding
Disperse radiation occurs when the beam interacts with the patient’s surface, causing radiation residuals to
scatter. The backscatter shield significantly minimizes the operator’s radiation dose.
Internal Protection
The internal radiation shielding is optimally constructed to shield the operator from radiation Leakage.
Ergonomic design enables Always-Ready exposures
Preset exposure dose
In addition, operators can quickly capture an image by applying a preset dose to the patient and teeth
300+ exposures on a full charge
The XVbeam1000 supports up to 300+ exposures* on a single charge of its built-in battery.*(Exposure time: 0.5 sec)
Docking station
The XVbeam1000 is outfitted with an innovative docking station that enables its use whenever exposure is required. By returning the device to its docking station after each usage, it will be automatically recharged
Secure strap
The XVbeam1000’s strap design is more secure for users with smaller hands.
Technical Specification
- Focal Spot : 0.4 mm
- Tube Voltage (kV) : 65 kV
- Tube Current (mA) : 2.6 mA
- Exposure Time Range : 0.01~2 sec
- Inherent filtration : 0.8 mmAl/75kV
- Additional Filtration : 1.0 mmAl
- Source to Skin Distance : 200 mm
- X-ray Field : 60 mm Round
- Power Input : 22.2 V
- Weight : 2.1KG
XPECT Vision – Made in China
